How to Put Oil in Car: A Step-by-Step Guide

Adding oil to your car is a crucial aspect of routine maintenance that not only saves money in the long run but also extends the life of your car.

It’s a simple process that we can handle ourselves, ensuring that the engine runs smoothly and efficiently.

Proper lubrication reduces wear, minimizes friction, and helps maintain your vehicle’s reliability.

We’ll guide you through the steps to add oil to your car, ensuring you can keep your vehicle in top condition without incurring extra costs at the mechanic.

A hand holding a funnel over the open oil cap of a car engine, pouring oil into the reservoir

It’s imperative to periodically check the engine’s oil level and top off as needed between oil changes.

This preventive habit can catch potential issues early and keep your car’s performance at its peak.

Understanding how to properly perform this task means we’re helping to protect one of our most significant investments—our car.

Adhering to the manufacturer’s specifications for the right grade and quantity of oil ensures the longest life for your car’s engine.

Let’s take a closer look at how we can accomplish this essential task with ease and confidence.

Selecting the Correct Engine Oil

A hand pouring engine oil into a car's oil reservoir, following the recommended viscosity and type for the vehicle's engine

When we perform an oil change, using the correct type of oil is crucial for engine performance and longevity.

The type of engine oil we choose needs to match our vehicle’s specific requirements, including viscosity and whether it’s synthetic or conventional, as these directly affect how well the engine is lubricated under different conditions.

Understanding Viscosity and Ratings

Viscosity refers to the thickness of the oil and its ability to flow at varying temperatures.

The viscosity rating, often depicted on oil containers as two numbers separated by a “W” (e.g., 5W-30), represents the oil’s flow at zero degrees Fahrenheit and its flow at a regular engine operating temperature, respectively.

The lower the first number, the better the oil flows in cold weather.

We must ensure that the oil’s viscosity supports both the low and high-temperature ranges that our engine will operate in.

Key Point: Always check your vehicle’s manual for the manufacturer recommended oil viscosity and stick to it.

Organizations like the American Petroleum Institute (API) and the Association des Constructeurs Européens d’Automobiles (ACEA) provide ratings to classify oil types based on their performance standards.

For instance, API’s “SN” rating signifies that an oil type is designed for modern engines with specific performance requests.

Synthetic vs Conventional Oil

Synthetic oil is artificially made with chemical compounds that provide a higher level of engine protection and performance under a wide range of temperatures and conditions.

It is particularly beneficial for high-performance engines.

In contrast, conventional oil is derived from crude oil and offers sufficient lubrication under most driving conditions, usually favored by vehicles with simpler engine designs and drivers with regular driving patterns.

Synthetic Oil Conventional Oil
Better overall lubrication Sufficient for regular use
More expensive More affordable
Longer change intervals Shorter change intervals

Renowned brands like Mobil and Shell offer a range of synthetic and conventional oils that meet various API and ACEA specifications.

We must consult our vehicle’s manual to understand which oil type is recommended by the manufacturer and whether synthetic or conventional oil is more suited to our car’s specific model and driving habits.

Executing an Oil Change Step-by-Step

To ensure your vehicle maintains peak performance, it’s essential to regularly change the oil.

Proper preparation and executing the oil change process with attention to detail will help keep your engine running smoothly.

Gathering Necessary Supplies

Before we begin, let’s assemble all the instruments and materials we’ll require.

This ensures that the oil change is completed efficiently and safely.

  • A quality motor oil that matches your car’s recommended oil viscosity
  • A new oil filter specific to your car’s year and model
  • An oil filter wrench
  • A suitable socket or wrench for the drain plug
  • A sturdy set of jack stands
  • An oil drain pan
  • A funnel for adding oil
  • A kitchen towel or rags for cleanup
  • New gloves to keep your hands clean
  • Safety glasses to protect your eyes from splashes

Check the owner’s manual to determine the correct oil change interval and oil type for your specific vehicle model.

Performing the Oil Change

Now, let’s start the step-by-step process of changing your oil.

Firstly, ensure the vehicle is parked on a flat surface and that you’ve placed it on jack stands for safety.

The engine should be warm to allow for better fluid flow but not hot to avoid burns.

Step Action
1. Drain Old Oil Locate the oil pan under the engine bay. Position your oil drain pan underneath and carefully remove the oil drain plug with a wrench. Allow the old oil to completely drain out.
2. Replace Oil Filter Remove the old oil filter using the oil filter wrench. Apply a dab of motor oil to the gasket on the new filter and screw it in place, hand-tight.
3. Add New Oil Replace the oil drain plug securely. Use a funnel to pour new, fresh oil into the engine via the oil cap. Check your owner’s manual for the proper amount of oil required for your car’s engine.
4. Check Oil Level After adding oil, wait a few minutes for it to settle, then use the dipstick to check the oil level. Add more oil as needed to reach the full mark on the dipstick.

Once you’ve verified the oil level on the dipstick reaches the full mark, start the engine and let it run for a minute.

This circulates the oil and allows you to check for any leaks.

Confirm there’s no oil dripping from the oil drain plug or filter area.

After the engine has cooled, do a final check of the oil level and top up if necessary.

Dispose of the old oil properly by taking it to a recycling center or automotive store that accepts used oil.

Troubleshooting Common Oil Issues

When maintaining optimal engine health, ensuring proper oil levels and quality is crucial.

Let’s tackle two common oil-related problems: leaks and the repercussions of overfilling or contamination, and understand how to address them effectively.

Identifying and Fixing Leaks

If you notice a puddle under your car or a drop in the oil level without adding oil, you could have a leak.

Engine oil leaks often originate from the oil pan or gaskets.

Follow these steps to identify and rectify oil leaks:

Step 1: Check for Leaks

  • Clean the oil pan and surrounding areas.
  • Place a cardboard under the engine overnight.
  • Inspect for drips to locate the leak source.

Step 2: Replace or Repair

  • For minor leaks, try tightening the oil pan’s bolts.
  • If a gasket fails, it may require replacement.
  • Consult a lube shop for complex leaks, as repairs can prevent costly future damages.

When dealing with engine oil leaks, it’s critical to act swiftly to avoid extensive damage, like a loud engine noise indicating low oil level, which may lead to expensive repairs.

Addressing Overfilling and Contamination

Overfilling your car with engine oil or using contaminated oil can be as damaging as having low oil levels.

It can lead to increased pressure, leaks, and engine damage.

Here’s how to prevent and solve overfilling and contamination:

Preventing Overfilling

  • Always check the engine oil level using the dipstick before adding oil.
  • Add oil gradually and recheck the level to ensure it’s within the safe range.

Resolving Contamination

  • Perform regular oil changes according to the manufacturer’s recommendations.
  • Use quality engine oil to avoid dirty oil that can clog your system.
  • If overfilled, drain the excess oil or visit a professional for assistance.

Maintaining Your Vehicle Beyond Oil Changes

Regular oil changes are a fundamental part of car maintenance, but there’s much more we can do to ensure our vehicles operate efficiently and reliably.

Proper care extends the life of a car, enhances performance, and can save us significant money in the long run.

Regular Inspection and Maintenance

Understanding Your Vehicle’s Technical Specifications

Before we start any form of maintenance, knowing the technical specifications of our engine and other systems is essential.

Each make and model has specific requirements that we need to adhere to, including the type of oil, coolant, and other fluids it needs.

Keeping Up With Fluids and Filters

Besides the engine oil, our vehicle relies on various fluids to operate smoothly:

  • Transmission fluid
  • Coolant
  • Brake fluid
  • Power steering fluid

We need to check these fluids regularly and top them up or replace them according to the manufacturer’s schedule.

Replacing the oil filter and checking the gasket for wear at each oil change also prevents leaks and maintains engine health.

Checking Belts and Hoses Inspecting the Brakes Maintaining the Battery
Examine belts for cracks and hoses for leaks. Listen for squeaking and ensure pads are not worn. Clean terminals and test battery life.

Fuel efficiency can be greatly influenced by how well we maintain our vehicle.

Regularly checking and fixing alignment issues ensures that our steering remains responsive and our tires wear evenly, both of which can improve fuel economy.

We should also pay attention to our car’s dashboard indicators.

Warning lights alert us to potential problems, and we should address these as soon as they appear to prevent further issues.

Finally, replace wiper blades as soon as they begin to streak to maintain visibility during adverse weather conditions.

Regular vehicle checks and adherence to maintenance schedules keep us and our vehicles on the road safely and economically.
