How to Measure Hub Bore: A Step-by-Step Guide for Accurate Sizing

Measuring the hub bore of a wheel is a crucial step in ensuring a perfect fit between your vehicle’s wheel and the axle.

Hub bore, also known as wheel center bore, represents the hole at the center of a wheel that fits onto the axle of the car.

A precise measurement is key for hub-centric wheels, where the wheel’s center bore matches exactly with the axle, to distribute the weight of the vehicle and minimize vibration.

It’s important to get this right as improper fitment can lead to issues on the road.

A caliper measures the hub bore diameter of a wheel. The tool is placed inside the hub to determine the precise size

To measure the hub bore accurately, you’ll need a tool known as a caliper.

Using the caliper, you can determine the inside diameter of the wheel’s center bore.

This measurement is typically recorded in millimeters.

Knowing the exact size is especially important when purchasing aftermarket wheels or if you need hub centric rings, which are used to fill any gap between the wheel bore and the axle.

These rings help ensure the wheel is perfectly centered on the hub, preventing any potential wobble or misalignment.

When measuring the hub bore, make sure the wheel is faced down on a flat surface to avoid any errors.

It’s also important to zero the caliper before taking a measurement to guarantee precision.

Once the measurement is taken, you can use it to select the appropriate hub centric rings.

These rings will ensure a snug fit and a safe, smooth drive.

Remember that a wheel that is properly centered will reduce stress on wheel studs or bolts, contributing to the longevity of these components.

Exploring Hub-Centric Rings

We begin our exploration of hub-centric rings by understanding their crucial role in ensuring a snug and accurate fit between the wheel and vehicle hub.

As we dive into the components and significance of these rings, we see that they are not just optional accessories but in fact essential components for vehicle safety and performance.

Importance of Hub Centricity in Wheel Fitment

Vehicles require precise wheel centering to maintain stability and reduce vibrations.

Hub-centric rings serve to align and center the wheel on the vehicle’s hub, eliminating potential gaps.

Without these rings, the wheel may rely solely on the lug nuts for centering, which can lead to vibrations, particularly at higher speeds.

These rings provide a straightforward solution: they fill the space between the wheel’s center bore and the hub diameter.

When wheels are accurately centered on the hub, even distribution of weight occurs, reducing the chance of vibration.

Precisely measured hub-centric rings are vital for vehicles with aftermarket wheels as these wheels often have a larger center bore to fit a variety of vehicles.

Materials and Construction of Hub-Centric Rings

The construction of hub-centric rings can involve different materials, chiefly plastic or aluminum. Here’s how they compare:

Plastic Rings Aluminum Rings
More cost-effective and corrosion-resistant More durable and offer a more exact fit
Easy to install but can degrade over time Higher resistance to heat and mechanical stress

It’s often a matter of preference and use case when choosing between the two materials.

However, we emphasize that either type, when correctly sized, will function effectively to prevent vibrations and ensure the wheel is perfectly centered on the hub.

Correct Measurement for Wheel Upgrades

In upgrading wheels, accurate measurement of the wheel’s center bore and the vehicle’s hub diameter ensures compatibility and safety.

Precise use of tools like a digital caliper is critical for these measurements. Let’s address how to measure these dimensions correctly.

Measuring Wheel Center Bore and Hub Diameter

Tools Needed:
  • Digital Caliper
  • Ruler or Tape Measure (as backup)

To measure the wheel center bore, we use a digital caliper.

We measure the interior diameter of the wheel where it will mate with the hub.

This measurement should be taken in millimeters for precision.

It’s essential the caliper is positioned straight across the bore to avoid an inaccurate reading.

For the hub diameter, we also leverage the digital caliper.

We measure the diameter of the vehicle’s hub where the wheel center bore will sit.

The measurement requires the same level of precision, ensuring the hub rings, if necessary, will fit snugly to prevent vibrations.

The Role of PCD in Wheel Alignment

Understanding the Pitch Circle Diameter (PCD)

The Pitch Circle Diameter (PCD) is the diameter of an imaginary circular line which goes through the center of all the bolt holes.

It’s an essential measurement when considering wheel upgrades as it must match that of your vehicle’s hub.

A mismatched PCD can lead to improper wheel alignment, compromised safety, and potentially irreversible damage to the vehicle.

Measuring the PCD requires identifying the number of bolts and measuring the distance between the centers of opposite bolt holes.

In cases of an even number of bolts, the measurement can be taken directly.

However, with an odd number of bolts, we measure from any bolt hole center to a point halfway between two bolt holes directly across from the first.

The PCD should be measured in millimeters to maintain consistency with wheel center bore and hub diameter measurements.

Practical Guide to Installation

Before we begin, understand that proper installation of hub-centric rings is crucial for achieving a perfect fit between your wheel and hub.

This ensures not only aesthetic alignment but, most importantly, a safe and smooth driving experience.

Steps for Installing Hub-Centric Rings

1. Identify the Correct Sizes

Firstly, we must find the hub ring sizes that match our vehicle’s hub size and the wheel’s center bore.

Our hub’s inner diameter and the wheel’s inner diameter are essential measurements.

Let’s use a digital or manual vernier caliper for the most precise measurements.

2. Clean the Hub Interface

Before installation, it’s our job to clean the hub surface thoroughly to remove any debris or corrosion.

This will ensure a snug fit for the hub-centric rings.

3. Install the Hub-Centric Rings

Carefully place the hub-centric rings onto the hub.

The fit should be tight but not forced.

The ring should sit flush against the hub, and the outer diameter of the ring should match the wheel’s bore perfectly.

Ensuring Perfect Wheel Fitment

Check the Wheel Fitment

After installing the rings, we’ll place the wheel back onto the hub.

As we do, we must ensure the ring guides the wheel onto the hub without any discrepancies.

They should align effortlessly if we’ve selected the correct size.

Aspect Before Installation Inspection During Installation Checks After Installation
Hub Surface Cleanliness Hub Ring Fitment Wheel Alignment with Hub
Proper Ring Sizes Ease of Wheel Placement Lug Nut Tightness


Secure the wheel by tightening the lug nuts in a star pattern.

This will distribute the load evenly and ensure the wheel is centered on the hub.

The lug nuts should be tightened to the manufacturer’s specified torque for safety.

Troubleshooting Common Issues

Correctly assessing and addressing hub bore issues will ensure that your vehicle’s wheels fit properly and perform at their best.

These steps can help resolve two common issues: vibrations and improper fitment of hub-centric rings.

Dealing with Vibrations and Wobbling

  • Inspect the wheel center bore and hub diameter: Confirm that the wheel bore is concentric with the hub.
  • Check for dirt and debris: Clean the hub surface as foreign particles can cause an uneven fit.
  • Examine the condition of the hub-centric rings: Look for wear and tear that can affect the fitment.
  • Test the wheel balance: An unbalanced wheel can lead to vibrations regardless of the hub fitment.

When to Replace Hub-Centric Rings

Hub-centric rings are essential when there’s a size difference between the wheel’s center bore and the vehicle’s hub. They are designed to fill the gap and ensure the wheel is perfectly centered on the hub, preventing any off-center rotation which can cause vibrations.

We should consider replacing these rings if:

Issue Resolution Preventive Action
Visible gap between the wheel and the hub Replace with the correct size rings Regularly check for snug fitment
Cracked, warped, or broken hub-centric rings Immediate replacement to ensure safe driving Inspect the rings during tire rotation or wheel removal

By following these guidelines, we can effectively manage hub-related issues that affect ride quality and safety.
