Subaru Crank Pulley Bolt Size: Your Comprehensive Guide to Specifications

A reliable vehicle is crucial to our daily life, and Subaru owners know this well.

One key component needing periodic attention is the crankshaft pulley, fastened securely to the engine via the crank pulley bolt.

It’s vital to ensure this bolt is the correct size for optimal engine performance and service longevity.

Understanding the precise size for your Subaru’s crankshaft pulley bolt is crucial, whether you’re carrying out routine maintenance, upgrading, or troubleshooting issues.

A mechanic uses a socket wrench to tighten a large crank pulley bolt on a Subaru engine

Subaru vehicles encompass a range of models, each potentially requiring a different bolt size.

Across various forums and technical resources, owners of different models like the Forester and Outback have highlighted the importance of using the exact bolt size to avoid damaging internal threads or compromising the crankshaft’s functionality.

In our experience, the specifications of the bolt often depend on the engine type and the model year, reflecting Subaru’s engineering updates over time.

We’ve seen that incorrect bolt sizes can lead to a multitude of engine problems, from pulley wobble to catastrophic engine failure.

So, whether you are considering a DIY repair or seeking professional service, it’s imperative to source and utilize the correct crankshaft pulley bolt size for your particular Subaru model.

The attention to this detail can save us from a string of potential issues that can affect our vehicles down the road.

Identifying the Correct Tools for Subaru Engine Maintenance

When undertaking maintenance on your Subaru’s engine, especially when addressing tasks such as removing the crank pulley bolt, it’s critical we select the proper tools.

The crank pulley bolt is renowned for requiring substantial torque to loosen and tighten, making the right choice of tools not just a convenience but a necessity for the job.

Essential Tool List:
  • Socket: A high-quality, 22mm socket is integral.
  • Impact Wrench: Facilitates the loosening of the bolt without manual strain.
  • Breaker Bar: Grants additional leverage when an impact wrench isn’t enough.
  • Screwdriver Set: Useful for miscellaneous tasks during the process.
  • Pipe Extension/Cheater Pipe: Adds length to the breaker bar, enhancing leverage.

To begin, ascertain that your tools are up for the challenge.

A sturdy 22mm socket tailored for high-torque applications is essential to grip the bolt effectively.

Incorporate an impact wrench into our arsenal for the benefit of its high-torque capabilities, saving time and effort.

In instances where an impact wrench isn’t at our disposal or fails to loosen the bolt, employing a breaker bar is our next best option.

We can enhance the breaker bar’s efficiency by attaching a pipe extension—commonly known as a ‘cheater pipe’—to supply us with the extra leverage necessary to overcome the bolt’s resistance.

Ensure all tools are in good condition before proceeding with engine maintenance to avoid injury and tool damage.

Finally, it’s prudent we consult the service manual specific to our Subaru model.

This manual will provide the exact specifications and may recommend additional tools or techniques pertinent to the task at hand, ensuring we undertake maintenance correctly and safely.

Dismantling Process: Removing Pulleys and Bolts

Removing the crankshaft pulley and its retaining bolt from a Subaru requires precision and an understanding of the bolt’s specifics. We focus on the direct steps to extract pulleys and bolts without causing damage.

Extracting Pulley and Bolts Efficiently

When intending to remove the crankshaft pulley or harmonic balancer, it’s crucial to immobilize the pulley.

We make use of a strap wrench or similar tool to hold the pulley in place while loosening the bolt.

It’s important to ensure that the engine is not running, and the car is in gear (preferably first gear in manual transmissions) to avoid movement.

The size of the bolt head typically requires a 22mm socket attached to a breaker bar.

If the bolt is particularly stubborn, we may employ the ‘shock’ technique, which involves striking the end of the breaker bar with a hammer to aid in releasing the bolt.

Handling the Crankshaft Pulley Bolt

The crankshaft pulley bolt, for its part, demands attention regarding torque specifications when being re-installed.

We consult the manufacturer’s torque specifications which generally stipulate around 130 foot-pounds.

It is imperative to tighten the crank pulley bolt incrementally to avoid cross-threading and ensure an even application of torque.

Threads should also be clean and lightly oiled before the bolt is reinstalled.

We use a torque wrench for final tightening to guarantee the bolt is secured accurately according to specifications.

Additionally, ensure that the keyway or woodruff key aligning the pulley to the crankshaft is in good condition; this is crucial for the synchronization of the engine’s timing components.

⚠️ A Warning

Over-tightening or improper alignment can lead to premature wear of the crankshaft pulley or damage to the bolt, compromising engine integrity.

Timing Belt Replacement and Torque Specifications

When replacing a Subaru’s timing belt, attention to torque specifications is vital for the vehicle’s performance.

The process not only involves installing a new timing belt but also ensuring that each component is secured with the correct torque, which allows the engine to run smoothly.

Timing Belt Installation

Installation Steps:
  • Initially, we align the timing marks on both the crankshaft and camshaft, ensuring the engine is set to top dead center.
  • Next, we install the belt onto the pulleys, starting with the crankshaft sprocket and working counterclockwise.
  • It’s essential to maintain proper tension on the belt to avoid slippage or misalignment.

Applying Correct Torque Settings

The correct application of torque during a timing belt job is critical to the longevity and safety of the engine.

Under-torquing can lead to loosening of parts, while over-torquing may cause bolt or component damage.

Crank Pulley Bolt Torque: 130.2 lbf-ft after oiling the seat and threads.
  • For the idler pulley, typically we use a torque setting of 29 ft-lbs, but it’s essential to refer to specific model manuals as variations can occur.
  • When working with bolts, especially aluminium pulleys, we must ensure not to exceed their torque limits, as they are susceptible to stripping or breaking.
⚠️ Warning

Double-check torque specifications for your particular Subaru model before applying them, as specifications can differ between models and engine types.

  • We recommend using a calibrated torque wrench to achieve the precise torque value and prevent potential issues associated with incorrect torque.

Subaru Vehicle Models: Specific Maintenance Tips

When maintaining various Subaru models, it’s crucial to account for the unique specifications and maintenance needs of each.

Whether it’s the robust Outback or the performance-centered WRX, understanding the nuances ensures longevity and peak performance.

Handling Different Subaru Models

Subaru vehicles like the Outback, Forester, Legacy, Impreza, and Baja each have their own maintenance requirements, particularly regarding their crank pulley bolt sizes.

For example, the bolt size for a 1996 Legacy would differ from that of an Impreza.

We recommend referring to the vehicle-specific service manual for precise specifications. Here’s a quick reference for some common Subaru models:


Model Crank Pulley Bolt Size Torque Specifications
Legacy Varies by year Refer to manual
Outback Different for various trims like XT, Limited 130.2 lb-ft + torque angle for some
Forester Check service manual 94 ft-lbs to 130.2 lb-ft typically

Special Considerations for Turbocharged and MT Models

Turbocharged Subaru models, such as the WRX or the Forester XT, as well as manual transmission (MT) vehicles like the STI, require additional attention.

It’s essential to ensure that the crank pulley bolt is secured to the manufacturer’s torque specifications to handle the enhanced performance demands.

For turbo models such as the GT Limited or the XT Limited, and vehicles equipped with MT, it’s not just about the bolt size but also about the correct installation technique to prevent premature wear.

We also need to be mindful of the unique stress these engines endure, making it crucial to check the integrity of the bolt periodically.

Consistent maintenance is the key to reliability, particularly with the increased power and torque in these performance models.

Remember: For any model, especially for turbocharged and MT models, using a torque wrench to ensure proper tightening of the crank pulley bolt is fundamental.
